G6-RK3588 AI Edge Gateway

Industrial PCs/ Industrial Computer Module/ Industrial Computer Module/ G6-RK3588 AI Edge Gateway

G6-RK3588 AI Edge Gateway

Model:

G6-RK3588

Add To Compare

● Fanless aluminum design, industrial-grade stable AI Edge Device for 7×24h operation.

● RK3588 Edge Computer with 6TOPS NPU for local AI computing.

● Optional 8G/16G RAM + expandable 128/256/512GB M.2 NVMe SSD.

● Dual 8K HDMI outputs, 8K Video Analysis Edge PC for CV vision processing.

● Onboard WiFi+4G & dual Gigabit LAN, fully functional Industrial Edge Gateway.

● Dual RS232 COM ports for serial data collection and equipment debugging.

● Pre-installed Ubuntu 22.04 / Debian 11.

Data sheet Send Inquiry

The G6-RK3588-F13 is a fanless rugged Edge Computing Box engineered for smart city and industrial visual monitoring, a premium RK3588 Edge Computer with integrated gateway and edge AI capabilities. This robust 6TOPS NPU Edge Box carries an octa-core Rockchip CPU and dedicated NPU chip to run local AI analysis, eliminating cloud latency and reducing bandwidth consumption. Functioning as a reliable Industrial Edge Gateway, it features dual Gigabit LAN, dual RS232 serial ports, onboard 4G and WiFi to collect, filter and forward on-site data to remote cloud platforms. As a 8K Video Analysis Edge PC and versatile Vision Edge Computing Device, it offers dual 8K HDMI output, expandable NVMe storage and Ubuntu/Debian OS. Suitable for smart parks, intelligent traffic, smart fishery and kitchen safety, this industrial AI Edge Device enables real-time local recognition, alerting and autonomous control.

Overview
Specification

Smart Industrial Scenarios with AI Video Analysis

This powerful 8K Video Analysis Edge PC delivers reliable on-site visual processing as a versatile AI Edge Device. It supports multi-camera local video analysis, real-time AI target recognition and seamless edge-cloud data sync, running stably 24/7 for outdoor and indoor deployments. Ideal for smart city, intelligent traffic, factory visual inspection, smart fishery and energy monitoring, it cuts cloud bandwidth costs and enables instant local alerting for all industrial IoT monitoring projects.

Edge-cloud AI Computing Workflow

Multi-camera local processing: On-site video analysis reduces bandwidth load.

Real-time AI traffic detection: Instantly identifies license plates, hazards, and targets.

Edge-cloud synergy: Rugged 24/7 outdoor operation with cloud data synchronization.

ARM RK3588 Octa-core solution

Adopts 8nm octa-core RK3588 SoC for this high-performance RK3588 Edge Computer. Optional 8GB/16GB LPDDR4 RAM, onboard 64GB/128GB eMMC, plus M.2 2280 NVMe/SATA expansion slot. As a reliable Edge Computing Box, it provides ample local cache space for multi-task data processing and long-running edge gateway data recording.

6TOPS Edge Device-Local AI Computing

This 6TOPS NPU Edge Box & RK3588 Edge Computer packs a dedicated 6TOPS NPU, Mali-G610 GPU and 48MP ISP with full 8K codec support. It works as a professional Vision Edge Computing Device, compatible with mainstream AI frameworks. Developers deploy custom CV algorithms for low-latency local inference, lowering cloud bandwidth and meeting diverse industrial visual secondary development needs.

Dual Isolated Gigabit Ethernet

Equipped with dual independent Gigabit LAN ports, this robust Industrial Edge Gateway realizes physical isolation between on-site OT equipment network and cloud IT network. Separately connect cameras, PLCs and remote cloud platforms, safely filter and transmit industrial data to avoid cross-network security risks for all IoT projects.

2 RS232 for Industrial Serial Collection

Two built-in RS232 COM ports are designed for industrial data collection of sensors and inverters, expandable to RS485. As a multi-functional AI Edge Device, it stably collects serial device data and supports on-site debugging, perfectly matching factory automation and equipment monitoring edge solutions.

Dual-Band WiFi + 4G LTE

Built-in 2.4G/5G dual-band WiFi + Bluetooth, with SIM slot for optional Quectel 4G module. This versatile Industrial Edge Gateway supplies triple network backup (wired + WiFi + 4G). It delivers stable remote cloud upload for field sites without fixed broadband, ideal for outdoor edge monitoring deployment.

Specification G6-RK3588

Part No.

G6-RK3588
Get A Quote
System

SOC

4*Cortex-A76 + 4*Cortex-A55

CPU

Rockchip RK3588

NPU

6TOPS，Support the installation of computing power sticks（M.2 2280 SATA/NVME）

Memory

8GB

Storage & Expansion

EMMC 128GB； SSD （M.2 2280 SATA/NVME）
Video

GPU

Mali-G610

Hardware Codec

JPEG Encoder/Decoder；8K Video Encoder (H265/H264...）；8K 10-bits Video Decoder (H265/H264/VP9/AV1...)

Display Interfaces

2*HDMI 2.1 ； Supports heterogeneous display; 4K resolution output, up to 8K@60HZ
Network

Ethernet

Dual Gigabit Ethernet

Wireless Network

2.4G+5G Dual-band WIFI+Bluetooth
I/O

USB

2*USB3.0；4*USB2.0

RS232

2*RS232 （External RS485 conversion module can be installed）

Audio

AUX3.5* headphone output + AUX3.5* microphone input

SIM

1*SIM card slot; Supports built-in 4G/5G module
Others

Watchdog

Supports customization

RTC

Supported
Power Input

Power Input

DC 12V - 3A

Buttons/Indicators

Red/Green
Physical Parameters

Board Dimensions

133*126*36.5mm

Package Dimensions

245*190*60mm

Net Weight

0.57 KG

Gross Weight

0.95 KG
Software

Operating System

Ubuntu22.04；Android 12； debain11
Environment

Operating Temperature

-10~40°C (14~104°F)

Storage Temperature

-10~40°C (14~104°F)

Operating/Storage Humidity

0~85% RH (Non-condensing)

Safety Certifications

CCC，CE，ISO

Get A Quote

System

SOC

G6-RK3588

4*Cortex-A76 + 4*Cortex-A55
CPU

G6-RK3588

Rockchip RK3588
NPU

G6-RK3588

6TOPS，Support the installation of computing power sticks（M.2 2280 SATA/NVME）
Memory

G6-RK3588

8GB
Storage & Expansion

G6-RK3588

EMMC 128GB； SSD （M.2 2280 SATA/NVME）

Video

GPU

G6-RK3588

Mali-G610
Hardware Codec

G6-RK3588

JPEG Encoder/Decoder；8K Video Encoder (H265/H264...）；8K 10-bits Video Decoder (H265/H264/VP9/AV1...)
Display Interfaces

G6-RK3588

2*HDMI 2.1 ； Supports heterogeneous display; 4K resolution output, up to 8K@60HZ

Network

Ethernet

G6-RK3588

Dual Gigabit Ethernet
Wireless Network

G6-RK3588

2.4G+5G Dual-band WIFI+Bluetooth

I/O

USB

G6-RK3588

2*USB3.0；4*USB2.0
RS232

G6-RK3588

2*RS232 （External RS485 conversion module can be installed）
Audio

G6-RK3588

AUX3.5* headphone output + AUX3.5* microphone input
SIM

G6-RK3588

1*SIM card slot; Supports built-in 4G/5G module

Others

Watchdog

G6-RK3588

Supports customization
RTC

G6-RK3588

Supported

Power Input

Power Input

G6-RK3588

DC 12V - 3A
Buttons/Indicators

G6-RK3588

Red/Green

Physical Parameters

Board Dimensions

G6-RK3588

133*126*36.5mm
Package Dimensions

G6-RK3588

245*190*60mm
Net Weight

G6-RK3588

0.57 KG
Gross Weight

G6-RK3588

0.95 KG

Software

Operating System

G6-RK3588

Ubuntu22.04；Android 12； debain11

Environment

Operating Temperature

G6-RK3588

-10~40°C (14~104°F)
Storage Temperature

G6-RK3588

-10~40°C (14~104°F)
Operating/Storage Humidity

G6-RK3588

0~85% RH (Non-condensing)
Safety Certifications

G6-RK3588

CCC，CE，ISO
